CS-302D

CS-302D is the delegate microphone unit of the CS-302 conference system – a simple and cost-effective solution for meetings, discussions, and formal sessions. It features a high-definition OLED screen that displays microphone status, operating mode, and other key information in real time. The built-in speaker allows direct audio playback, while the 3.5 mm headphone output provides private listening.

The unit supports four operating modes, including a newly developed voice-activated (VOX) mode that enables hands-free microphone activation by simply speaking. A status indicator shows whether the microphone is active, muted, or in a waiting state. The system allows 2, 3, or 4 microphones to be active simultaneously, and up to 110 units can be connected using the EXP-124 expansion module.

Functionality:

• Delegate unit for the CS-302 conference system
• 4 operating modes including voice activation (VOX)
• OLED screen for microphone and system status
• Built-in speaker and 3.5 mm headphone output
• Microphone status indicator (active / muted / waiting)
• Supports up to 110 units (with EXP-124)
• Compatible with camera tracking and Dante output (system-level)

Product Features:

• Microphone type: capacitive, cardioid
• Frequency response: 50 Hz – 18 kHz
• Sensitivity: –47 dB ±3 dB (0 dB = 1 V/Pa, 1 kHz)
• Max input SPL: 105 dB (THD <5%, 1 kHz)
• S/N ratio: >52 dBA (A-weighted)
• Distortion: <0.1%
• Power supply: 24 V DC (from central unit)
• Speaker output: max 1.5 W
• Power consumption: 0.8–2.5 W
• Headphone jack: 3.5 mm stereo
• Display: OLED
• Interface: 9-pin aviation connector (male)
• Weight: approx. 950 g
• Microphone length: 340 / 420 (default) / 480 mm
• Base dimensions: 182 × 51 × 110 mm
• Color: nickel black

CS-302D is a reliable and user-friendly delegate microphone unit that delivers clear audio, intuitive operation, and seamless integration with the CS-302 system. Ideal for use in boardrooms, public institutions, and multilingual conference environments.
