DD-BN22

RDL DD-BN22 - wall-mounted bidirectional Dante 2x2 interface with microphone/line inputs and XLR outputs, PoE powered, white

The RDL DD-BN22 is a bidirectional Dante audio interface designed for wall mounting, connecting analog audio devices to the Dante network in both directions. It features two XLR inputs for microphones or line sources, which are sent to the network as two Dante transmit channels. It also has two XLR outputs for receiving two Dante channels at microphone or line level. This allows for connecting presenter microphones and outputting signals to cameras, recorders, podiums, or local sound systems from a single wall connection point. The device is powered via PoE from a network switch and mounts in a standard double electrical box or an RDL WB-2U box. All settings are changed using switches on the module, without special software. For each input, you can select microphone/line mode, enable 48V phantom power, and set gain, while for each output, you can choose microphone or line level. Discrete microphone preamps, 24-bit conversion, and RDL analog filtering ensure low noise and high sound quality. The stainless steel housing, metal XLR connectors, and white Decora plates combine durability with a discreet appearance on a light wall.

Functionality

• 2 XLR microphone/line inputs (female) as 2 Dante transmit channels
• 2 XLR microphone/line outputs (male) from 2 Dante receive channels
• Dante network: 100Mb/s Ethernet, RJ45 socket with Link and Speed indicators
• Sampling frequency 44.1kHz and 48kHz (default 48kHz), 24-bit resolution
• Operating level -20dBFS = +4dBu, reference level 0dBFS = +24dBu
• Microphone gain: 40dB, 48dB, or 62dB
• Line gain: 0dB, 8dB, or 19dB
• Maximum input level: microphone -16dBu, -24dBu, or -38dBu; line +24dBu, +12dBu, or +5dBu
• Input impedance: >2.5kΩ (microphone), >5kΩ (line)
• Switchable phantom power P48, 48V DC (IEC 61938:2013)
• Self-noise at input (EIN): -130dBu at 62dB gain, -132dBu A-weighted
• CMRR >65dB (50-120Hz)
• Frequency response of inputs and outputs: 20Hz-20kHz (±0.5dB)
• THD+N <0.1% (20Hz-20kHz), typically 0.015% at 1kHz
• Balanced outputs: line level +4dBu, max. +24dBu; microphone level -45dBu (50dB attenuation)
• Output impedance 150Ω, balanced
• Output noise: < -80dB below +4dBu, < -100dB below +24dBu
• Dynamic range of outputs above +4dBu: 20dB
• Crosstalk below noise level between inputs and between outputs
• A/D and D/A processing 24-bit, discrete microphone preamps, RDL analog filtering
• Configuration via switches, no special software required
• Sync and Power LEDs on the front, Link and Speed on the back
• PoE power, IEEE 802.3af, Class 0

Features

• Bidirectional Dante audio point in the wall of the room
• Settings changed on the fly, without a laptop or software
• Low-noise operation with dynamic and condenser microphones
• Power and signal over a single network cable
• Mounts in a standard double wall box or RDL WB-2U box
• Durable stainless steel housing and metal XLR connectors
• White Decora front plates, discreet on light walls
• Dimensions: 89.4mm x 104.4mm x 53.1mm
• Weight: 0.42kg
• Operating temperature: 0°C to 40°C (recommended max. 30°C)
• Product designed and manufactured in the USA
• 7-year RDL warranty for products purchased after 14.08.2026

RDL DD-BN22 is a bidirectional, wall-mounted Dante 2x2 interface with microphone/line inputs and XLR outputs, PoE power, and switch configuration. The white Decora plates, robust construction, and high audio quality make it well-suited for conference rooms, lecture halls, auditoriums, and office spaces where wall access to the Dante audio network is needed.
