MuxLab 500559-WH - Bluetooth and RCA/3.5mm Audio to Dante, White
MuxLab 500559-WH is a professional two-way audio transmission panel for Bluetooth, analog audio, and Dante, designed to integrate mobile devices and classic audio sources with modern AV systems. It enables wireless connection with phones, tablets, and other devices via Bluetooth 5.3, as well as wired connection through RCA and 3.5mm jacks. The received audio signal is converted to digital and transmitted over the Dante network, ensuring high quality and stable performance. The panel also supports audio output via Bluetooth and analog RCA/3.5mm outputs. Power, control, and audio data are transmitted through a single network cable using PoE, eliminating ground loop issues and simplifying installation. The device is compatible with standard US dual gang wall boxes with Decora faceplates. Gain selection (-12dB to 18dB) is available via Web-UI.
Q-SYS plugin available for this device. Click here to download.
Functionality
- Two-way audio transmission: Bluetooth, analog, and Dante
- Wireless Bluetooth 5.3 connection with mobile devices
- Wired RCA and 3.5mm stereo inputs and outputs
- Analog-to-digital conversion and Dante network transmission
- Power, control, and audio via single PoE cable
- Gain selection (-12dB to 18dB) via Web-UI
- Compatible with US wall boxes with Decora faceplates
- Supports AES67 RTP audio transport
- Integration with control systems via open API and Q-SYS plugin
Features
- Bluetooth 5.3 - extended range and stable connection
- Simple and intuitive Bluetooth pairing
- Compatible with most Apple smartphones, iPads, and Android tablets
- RCA and 3.5mm TRS stereo inputs/outputs
- PoE power (IEEE802.3af)
- Control via Dante Controller and Web-GUI
- Compatibility with professional AV installations
MuxLab 500559-WH is a versatile audio panel that enables easy integration of Bluetooth and analog sources with Dante network systems, providing flexibility, high audio quality, and simple installation in any professional AV environment.
