CM12

DSPPA CM12 - 6-zone desktop paging microphone

DSPPA CM12 is an advanced desktop microphone designed for zoned public address systems. It allows direct control of up to six independent audio zones - individually or in groups - using dedicated zone buttons. Its intuitive interface and fast access to functions make it ideal for public, commercial, and educational facilities.

The unit features a flexible gooseneck microphone, signal level meter, two built-in chime tones, and adjustable volume for both the microphone and warning signals. The RJ-45 connector supports cascading connections with other units, and full compatibility with the DSPPA MP912 matrix amplifier ensures seamless system integration.

Functionality:

• control of up to 6 audio zones - individual or grouped
• dedicated zone buttons - quick announcement activation
• signal level meter - output monitoring
• 2 built-in chimes - pre-announcement alerts
• adjustable mic and chime volume
• gooseneck microphone - flexible positioning
• RJ-45 connector - cascading support
• compatible with MP912 matrix amplifier

Features:

• mic frequency response: 100 Hz - 15 kHz
• line input frequency response: 20 Hz - 20 kHz
• mic sensitivity: 10 mW
• line input sensitivity: 2 V
• dimensions: 232 x 146 x 66 mm
• weight: 1.9 kg
• robust design - built for demanding AV environments

DSPPA CM12 is a reliable solution for managing voice communication in zoned PA systems, combining functionality, convenience, and high audio quality.
